Description

Available with the following options for output mode, field of view and lens size. Please enquire:

Lens Size options:
6.8mm
9.1mm

Output Mode:
USB
CVBS

Field of View:
48.9° x 39.1°
62.9° x 49.9°
48.3° x 38.6°

Detector type：Vanadium oxide uncooled infrared focal plane detector
Resolution：640×512
Lens millimeters：9.1mm
Pixel Pitch：12um
Spectral Band:8-14um
NETD:≤40mK
Shutter：Automatic shutter correction
Focusing：Adjustable focus
Aperture：1.0
FOV(H*V):48.3°(H)*38.6°(V)
Pseudo color:White heat
Standard:PAL
type of output:USB
Power supply voltage:4.5-18V
Size:20*20MM
Weigh:≤23g
